Structural Drawing Sets
A Structural Drawing Set is a set of plans prepared by a licensed professional engineer which is required to be approved by the City before construction phase for most projects.
4.6/5
Customer Ratings
6+
Years in the Industry
600+
Projects
Our Process
How we deliver this service from start to finish
Free Consultation
Please contact us via our website to schedule a free consultation
Free Quotation
We will provide a free quotation within 1 business day and a contract for signing
Clear Info Requirement
We will provide a list of documents required from you for our engineers to prepare the drawing set
Quick Turnaround
We will prepare the drawing set based on the info provided and share an ETA with a 3-week commitment
Follow-up Requests
We will address your comments or any additional requests and provide options for change orders (if needed)
City's Approval
After you submit our set to the City, SF Bay Engineering will address all plan check comments until the permit is approved
Licensed Engineers
Every project is led by a licensed California Professional Engineer with years of residential experience.
Code Compliant
All deliverables meet or exceed the latest California Building Code and local jurisdiction requirements.
Fast Turnaround
Industry-leading delivery times so your project stays on schedule and on budget.
Deliverables
What you receive with this service
SF Bay Engineering will provide Structural Drawing Sets in PDF format (CAD file can be provided upon request), which consists of Foundation Plan, Framing Plans, Notes and Details.
Project Types
Types of projects we handle with this service
Required Documents
Documents needed to get started on your project
For New Construction
- Proposed architectural plans (PDF + CAD)
For Existing Structures
- Proposed architectural plans (PDF + CAD)
- Architectural as-builts (PDF + CAD)
- Structural as-builts
- Soils report (as applicable)
Ready to Start Your Project?
Get a free consultation and competitive quote for your structural engineering needs
